Product Details:
|
| Sensor Size: | 1/4" | Specification: | HK-9139AS-648-1 |
|---|---|---|---|
| Wavelength: | λ 400-700nm（COLOR) | Field Of View (diagonal): | D：130° H 90° |
| Optical Distortion(diagonal): | ＜-30% | Element: | 4E + IR |
| High Light: | drone camera lenses 2.35mm,HFOV drone camera lenses,GTD Horizontal Field of View Lens |
||
HFOV Lens Drone Lens / UAV Lens Refrigerator Lens Microwave Oven Lens Video Doorbell Lens
Product Details
| Specification | HK-9139AS-648-1 |
| Sensor Size | 1/4" |
| Wavelength | λ 400-700nm(COLOR) |
| Focal Length(EFL) | f 2.35 mm |
| F/NO (Infinite) | F/NO 2.60 |
| Back Focal Length | BFL 3.72 mm |
| Flange back length | FB 2.69 mm |
| Field Of View (diagonal) | D:130° H 90° |
| Optical Distortion(diagonal) | ＜-30% |
| Thread Size | M12*P0.5 |
| Element | 4E+IR |
· Name: Lens
· Brand: GTD
· Material: rare metal
· Uses: smart homeware products, such as security and protection monitoring, APP Wifi camera, IP camera, smart digital door viewer, visual door bell, sweeping robot, refrigerator and air conditioner etc
Product features
Body worn camera/Video conference camera/Smart home&robot/Automotive camera lens
1. 360° panoramic surveillance CCTV camera lens.
2. High definition lenses with optical filter.
3. Can be used in multiple field
PRODUCTION PROCESS
1 check and clean materials
2 assemble bottom lens/spacer
3 assemble middle lens/spacer
4 waterproof rubber ring
5 assemble top lens
6 lock lid
7 profile check
8 surface check
9 gelling UV glue
10 solidify UV glue
11 waterproof test(air tightness test)
12 vibration test
13 clean surface dust cap
14 stick IR
15 spot check finish product/warehouse if qualified
