6±5% mm Focal Length Optical System with 70% RI

6±5% mm Focal Length Optical System with 70% RI
6±5% mm Focal Length Optical System with 70% RI

Large Image :  6±5% mm Focal Length Optical System with 70% RI

Product Details:
Place of Origin: CHINA
Brand Name: GTD
Certification: IATF 16949, ISO 9001
Model Number: JZ-8345B
Payment & Shipping Terms:
Minimum Order Quantity: 10pcs
Price: contact me
Packaging Details: The plastic box is loaded into the vacuum packaging bag and then loaded into the carton,also according to customers requirement
Delivery Time: 15 - 25 days after receipt of deposit / full amount
Payment Terms: T/T, L/C
Supply Ability: 500,000pcs/month

6±5% mm Focal Length Optical System with 70% RI

Description
Interface Type: M12*P0.5 (Ø16mm) Product Description: ADAS Camera Lens Wide Angle 2MP Infrared Vehicle Lens
F/NO (Infinite): F/NO 1.6 Sensor Size: OX08B40(3840×2160,2.1цm)
Optical Distortion (Diagonal): -3.25% Product Name: 8MP High-Resolution ADAS Camera Lens,wide-angle Wide Field Of View,Strong Customiz;Ø9.6,F/NO1.6
Field Of View (Diagonal): D34.4°±3° ; H30°±3° ; V 16.8°±3° Element: 8G+IR

Product Description:

The Field of View (Diagonal) is D34.4°±3°, H30°±3°, V 16.8°±3°, allowing for a wide range of coverage that is essential for 360-degree cameras. Whether you are using it for parking assistance or lane departure warning, this lens has got you covered.

The interface type is M12*P0.5 (Ø16mm), making it compatible with most cameras, and easy to install. This lens is designed to fit seamlessly with your existing camera system, ensuring that you can capture footage with ease.

The Sensor Size is OX08B40(3840×2160,2.1цm), which means that the clarity of the footage captured is of the highest quality. You can be sure that even in low light situations, this lens will provide you with clear and precise images.

The Element is 8G+IR, which means that it is made up of eight glass elements and an infrared filter. This combination helps to reduce glare and improve the quality of the images captured.

Our ADAS Camera Lens is perfect for those who need a reliable lens for their automotive camera. Whether you are using it for a 360-degree camera, parking assistance, or lane departure warning, this lens can handle it all. With its superior clarity, you can be sure that you will get the footage you need, even in low light situations.

Investing in our ADAS Camera Lens will ensure that you have the best lens for your automotive camera. Its versatility, compatibility, and superior image quality make it the perfect choice for anyone who needs an automotive lens. With night vision capabilities, it is sure to capture clear and precise images even in the darkest of situations.


Features:

  • Product Name: 8MP High-Resolution ADAS Camera Lens
  • Product Category: ADAS Camera Lens
  • Sensor Size: OX08B40(3840×2160,2.1цm)
  • Element: 8G+IR
  • Optical Distortion (Diagonal): -3.25%
  • Wide-angle wide field of view
  • Strong customizability
  • Night Vision capable
  • Compatible with 360-Degree Cameras
  • Automotive Lens
  • Size: Ø9.6
  • Aperture: F/NO1.6

Technical Parameters:

RI(%) 70%
CRA 20.1
Element 8G+IR
Focal Length(EFL) 6±5% mm
Material Aluminum, Glass, Plastic
Optical Distortion (Diagonal) -3.25%
Sensor Pixels (3840×2160, 2.1μm)
Flangle Back Lenght FBL/FFL 2.0
Product Description ADAS Camera Lens Wide Angle 2MP Infrared Vehicle Lens
Product Name 8MP High-Resolution ADAS Camera Lens, wide-angle wide field of view, Strong customiz; Ø9.6, F/NO1.6
Keywords Lane Departure Warning (LDW), Camera Module, Automotive Lens

Applications:

The GTD JZ-8345B ADAS Camera Lens is highly versatile and can be used in a variety of different scenarios. For example, it can be installed in buses, trucks, and other large vehicles to help drivers avoid collisions and stay safe on the road. It can also be used in personal vehicles to provide an extra layer of protection and peace of mind.

This product is certified according to IATF 16949 and ISO 9001 standards, ensuring that it meets the highest quality and safety standards. It has a maximum image height of Ø9.6 and sensor pixels of (3840×2160,2.1цm). The optical distortion (diagonal) is -3.25%, and the field of view (diagonal) is D34.4°±3°; H30°±3°; V 16.8°±3°. With these specifications, the GTD JZ-8345B ADAS Camera Lens is a reliable and accurate tool for advanced driver assistance systems.

The GTD JZ-8345B ADAS Camera Lens is available for purchase with a minimum order quantity of 10pcs. The price is available upon request, and we accept payment via T/T and L/C. With a supply ability of 500,000pcs/month, we can meet the needs of even the largest production lines. Delivery time is typically 15-25 days after receipt of deposit/full amount, and packaging is done according to customer requirements. The plastic box is loaded into the vacuum packaging bag and then loaded into the carton, ensuring that the product arrives in perfect condition.


Support and Services:

Our ADAS Camera Lens product comes with a comprehensive technical support and services package. Our team of experts is available to assist you with any technical issues you may encounter, such as installation, configuration, and troubleshooting. We also offer product training and on-site support, as well as warranty and repair services. Our goal is to ensure that your ADAS Camera Lens product operates at its optimal performance level, providing you with the highest quality images and data for your needs.


Packing and Shipping:

Product Packaging:

The ADAS Camera Lens will be packaged securely to ensure that it reaches you in perfect condition. The package includes:

  • ADAS camera lens
  • Instruction manual
  • Mounting hardware

Shipping:

The product will be shipped within 2 business days of receiving the order. Shipping options include standard delivery or expedited shipping for an additional fee. Shipping times may vary depending on your location and shipping option selected. You will receive a tracking number once your order has shipped.


FAQ:

Here are some frequently asked questions about the ADAS Camera Lens product:

Q: What is the brand name of this product?

A: The brand name of this product is GTD.

Q: What is the model number of this product?

A: The model number of this product is JZ-8345B.

Q: Where is this product manufactured?

A: This product is manufactured in China.

Q: What is the minimum order quantity for this product?

A: The minimum order quantity for this product is 10pcs.

Q: What is the price of this product?

A: Please contact us directly for pricing information.

Q: What are the payment terms for this product?

A: We accept T/T and L/C as payment terms.

Q: What is the supply ability of this product?

A: The supply ability of this product is 500,000pcs/month.

Q: What is the delivery time for this product?

A: The delivery time for this product is 15 - 25 days after receipt of deposit / full amount.

Q: How is this product packaged?

A: The plastic box is loaded into the vacuum packaging bag and then loaded into the carton. We can also customize the packaging according to customers' requirements.

Q: What certifications does this product have?

A: This product has IATF 16949 and ISO 9001 certifications.


8MP High-Resolution ADAS Camera Lens,wide-angle wide field of view,Strong customiz;Ø9.6,F/NO1.6

8MP High-Resolution ADAS Camera Lens,wide-angle wide field of view,Strong customiz;Ø9.6,F/NO1.6
