Product Details:
|
| Specification: | JZ-8348-1843-1-FS-FSN-LB | Sensor Size: | 1/2.7" |
|---|---|---|---|
| Focal Length(EFL): | EFL 2.35 Mm | Field Of View (diagonal): | D：164° H：142° V：79° |
| Optical Distortion(diagonal): | <-68% | Element: | 6G + 1IR |
| High Light: | OMS vehicle camera lenses,M12 vehicle camera lenses,2.35mm surveillance camera lens |
||
Car Camera Lens Vehicle Surveillance Camera Lens OMS M12 HD Waterproof Lens
· Name: Lens
· Brand: GTD
· Material: Glass
· Uses: There are products useful for car camera, security monitoring and vehicle. such as rear-view parking track, 360-degree panorama display, car DVR, ADAS and car night-vision device etc
Product Details
| Specification | JZ-8348-1843-1-FS-FSN-LB |
| Sensor Size | 1/2.7" |
| Wavelength | λ400-700nm(COLOR) |
| Focal Length(EFL) | EFL 2.35 mm |
| F/NO (Infinite) | F/NO 2.5 |
| Back Focal Length | BFL 4.65 mm |
| Flange back length | FB 3.20 mm |
| Field Of View (diagonal) | D:164° H:142° V:79° |
| Optical Distortion(diagonal) | <-68% |
| Thread Size | M12*P0.5 |
| Element | 6G + 1IR |
PRODUCTION PROCESS
1 check and clean materials
2 assemble bottom lens/spacer
3 assemble middle lens/spacer
4 waterproof rubber ring
5 assemble top lens
6 lock lid
7 profile check
8 surface check
9 gelling UV glue
10 solidify UV glue
11 waterproof test(air tightness test)
12 vibration test
13 clean surface dust cap
14 stick IR
15 spot check finish product/warehouse if qualified
Quality Guarantee
car camera drop-ball standard
salt spray test
waterproof test
against UV light
IP6K9K
IP68
ROHS
film strength's resistance to scratch
